轴径 | 轴承型号 | 类型 | 外形尺寸(min./mm) | 载荷(N) | 重量(kg) | |||
(d /min.) | D | c | B | Cr | Cor | |||
0.625 | 203KR2 | 4 | 1.5748 | 0.472 | 0.551 | 12800 | 6650 | 0.077 |
15.88 | 40 | 12 | 14 | |||||
0.64 | 203KRR2 | 1 | 1.5748 | 0.472 | 0.72 | 12800 | 6650 | 0.085 |
16.26 | 40 | 12 | 18.29 | |||||
0.515 | 203KRR5 | 1 | 1.5748 | 0.472 | 0.72 | 12800 | 6650 | 0.096 |
13.08 | 40 | 12 | 18.29 | |||||
0.64 | 203KRR6 | 1 | 1.8504 | 0.472 | 0.72 | 12800 | 6650 | 0.13 |
16.26 | 47 | 12 | 18.29 | |||||
0.669 | 203KRR7 | 1 | 1.5748 | 0.472 | 0.654 | 12800 | 6650 | 0.079 |
17 | 40 | 12 | 16.61 | |||||
0.7505 | 204KR2 | 4 | 1.7805 | 0.61 | 0.61 | 12800 | 6650 | 0.107 |
19.063 | 45.23 | 15.49 | 15.49 | |||||
0.7874 | 204KRR3 | 1 | 1.8504 | 0.551 | 0.699 | 12800 | 6650 | 0.121 |
20 | 47 | 14 | 17.76 | |||||
0.63 | 204KRD4 | 2 | 1.8504 | 0.551 | 0.689 | 12800 | 6650 | 0.135 |
16 | 47 | 14 | 17.5 | |||||
0.63 | 204KRR14 | 1 | 1.8504 | 0.591 | 0.72 | 12800 | 6650 | 0.142 |
16 | 47 | 15 | 18.29 | |||||
0.75 | 205KR3 | 5 | 2.0472 | 0.6992 | 0.6402 | 14000 | 7850 | 0.161 |
19.05 | 52 | 17.76 | 16.26 | |||||
1.0005 | 205KR4 | 3 | 2.0472 | 0.591 | 1 | 14000 | 7850 | 0.148 |
25.41 | 52 | 15 | 25.4 | |||||
1.181 | 206KR7 | 3 | 2.441 | 0.63 | 0.945 | 19450 | 11250 | 0.26 |
30 | 62 | 16 | 24 | |||||
1.181 | 206KRR8 | 1 | 2.441 | 0.63 | 0.945 | 19450 | 11250 | 0.26 |
30 | 62 | 16 | 24 | |||||
1.2598 | 206KRR18 | 1 | 2.441 | 0.63 | 0.945 | 19450 | 11250 | 0.219 |
32 | 62 | 16 | 24 | |||||
1.378 | 207KRR | 1 | 2.8346 | 0.669 | 0.984 | 25700 | 15200 | 0.35 |
35 | 72 | 17 | 28 | |||||
1.5748 | 208KRR2 | 1 | 3.1496 | 0.827 | 1.063 | 29500 | 18100 | 0.45 |
40 | 80 | 21 | 27 | |||||
1.9685 | 210KRR | 1 | 3.5433 | 0.7874 | 1.181 | 35000 | 23200 | 0.524 |
50 | 90 | 20 | 30 | |||||
2.7559 | 214KRR | 1 | 4.9212 | 1.1024 | 1.6929 | 62100 | 44800 | 1.546 |
70 | 125 | 28 | 43 |
