Cone | Max. Shaft Radius R | Cups | Max. Housing Radius r | Basic Load Ratings | Assm. | |||||
Number | Bore d | Width (cone) B | Number | Outer Dia. D | Width cup) C | Dynamic C (KN) | Static C0 (KN) | Total Assm. Width T | ||
X31307 | 35 | 21 | 2 | Y31307 | 80 | 15 | 1.5 | 61.6 | 67 | 22.75 |
1.378 | 0.8268 | 0.08 | 3.1496 | 0.5906 | 0.06 | 0.8957 | ||||
X31308 | 40 | 23 | 2 | Y31308 | 90 | 17 | 1.5 | 85 | 81.5 | 25.25 |
1.5748 | 0.9055 | 0.08 | 3.5433 | 0.6693 | 0.06 | 0.9941 | ||||
X31309 | 45 | 25 | 2 | Y31309 | 100 | 18 | 1.5 | 106 | 102 | 27.25 |
1.7717 | 0.9843 | 0.08 | 3.937 | 0.7087 | 0.06 | 1.0728 | ||||
X31310 | 50 | 27 | 2.5 | Y31310 | 110 | 19 | 2 | 122 | 120 | 29.25 |
1.9685 | 1.063 | 0.1 | 4.3307 | 0.748 | 0.08 | 1.1516 | ||||
X31311 | 55 | 29 | 2.5 | Y31311 | 120 | 21 | 2 | 121 | 137 | 31.5 |
2.1654 | 1.1417 | 0.1 | 4.7244 | 0.8268 | 0.08 | 1.2402 | ||||
X31312 | 60 | 31 | 3 | Y31312 | 130 | 22 | 2.5 | 145 | 166 | 33.5 |
2.3622 | 1.2205 | 0.12 | 5.1181 | 0.8661 | 0.1 | 1.3189 | ||||
X31313M | 65 | 33 | 3 | Y31313 | 140 | 23 | 2.5 | 165 | 193 | 36 |
2.5591 | 1.2992 | 0.12 | 5.5118 | 0.9055 | 0.1 | 1.4173 | ||||
X31314 | 70 | 35 | 3 | Y31314 | 150 | 25 | 2.5 | 172.9 | 220 | 38 |
2.7559 | 1.378 | 0.12 | 5.9055 | 0.9843 | 0.1 | 1.4961 | ||||
X31314D | 70 | 35 | 3 | Y31314D | 150 | 25 | 2.5 | 187 | 226.9 | 38 |
2.7559 | 1.378 | 0.12 | 5.9055 | 0.9843 | 0.1 | 1.4961 | ||||
X31315 | 75 | 37 | 3 | Y31315 | 160 | 26 | 2.5 | 209 | 245 | 40 |
2.9528 | 1.4567 | 0.12 | 6.2992 | 1.0236 | 0.1 | 1.5748 | ||||
X31318 | 90 | 43 | 4 | Y31318 | 190 | 30 | 3 | 264 | 315 | 46.5 |
3.5433 | 1.6929 | 0.16 | 7.4803 | 1.1811 | 0.12 | 1.8307 | ||||
